| 13MP OmniVision OV13B10 MIPI Interface Fixed Focus Camera Module |
| Model No. KLT-MFA31-OV13B10 V1.0 |
| Camera Module No. |
KLT-MFA31-OV13B10 V1.0 |
| Resolution |
13MP |
| Image Sensor |
OV13B10 |
| Sensor Type |
1/3.06" |
| Pixel Size |
1.12 um x 1.12 um |
| EFL |
2.33 mm |
| F.NO |
2.40 |
| Pixel |
4208 x 3120 |
| View Angle |
160.0°(DFOV) 118.0°(HFOV) 86.0°(VFOV) |
| Lens Dimensions |
10.00 x 10.00 x 14.00 mm |
| Module Size |
30.00 x 10.00 mm |
| Module Type |
Fixed Focus |
| Interface |
MIPI |
| Auto Focus VCM Driver IC |
None |
| Lens Type |
650nm IR Cut |
| Operating Temperature |
-30°C to +85°C |
| Mating Connector |
AXE530124 |
|
