5MP GalaxyCore GC05A2 Fixed Focus USB 2.0 Camera Module
|
| Model No. KLT-UFA79-GC05A2 V1.0 |
| Camera Module No. |
KLT-UFA79-GC05A2 V1.0 |
| Resolution |
5MP |
| Image Sensor |
GC05A2 |
| Sensor Type |
1/5" |
| Pixel Size |
1.25 um x 1.25 um |
| EFL |
2.20 mm |
| F.NO |
2.20 |
| Pixel |
2592 x 1944 |
| View Angle |
77.8°(DFOV) 65.9°(HFOV) 51.3°(VFOV) |
| Lens Dimensions |
6.50 x 6.50 x 4.55 mm |
| Module Type |
Fixed Focus |
| Interface |
USB 2.0 |
| Output Format |
MJPG / YUV2 |
| Auto Control |
Saturation, Contrast, Acutance
White Balance, Exposure |
| Audio |
Optional |
| Input Voltage |
DC 5V |
| Working Current |
Max 500mA |
| PCB Size |
60.00 x 7.50 mm |
| System Compatibility |
Windows XP (SP2, SP3), Vista, 7, 8, 10, 11
Android, Mac OS, Linux or OS with UVC Driver
Raspberry Pi by USB Port |
| Software for USB Camera |
AMCAP, Webcam Viewer, V4L2 Controls
Contacam, VLC Player, MotionEye OS
iSpy, ZoneMider, Yawcam |
| Lens Type |
650nm IR Cut |
| Operating Temperature |
-20°C to +70°C |
| USB Cable |
USB Cable |
|
