Home >> Products >> 8MP AF MIPI >> SONY IMX317 >> KLT-MAA44-IMX317 V1.0



        8.51MP Sony IMX317 MIPI Interface M12 Auto Focus Camera Module
        Model No.   KLT-MAA44-IMX317 V1.0










 Camera Module No. KLT-MAA44-IMX317 V1.0
 Resolution 8.51MP
 Image Sensor IMX317
 Sensor Type 1/2.5"
 Pixel Size 1.62 um x 1.62 um
 EFL 3.38 mm
 F.NO 2.20
 Pixel 3840 x 2160
 View Angle 85.8°(DFOV) 77.5°(HFOV) 48.8°(VFOV)
 Lens Dimensions 18.00 x 18.00 x 16.30 mm
 Module Size 33.00 x 22.00 mm
 Module Type Auto Focus
 Interface MIPI
 Auto Focus VCM Driver IC DW9714P
 Lens Type 650nm IR Cut
 Operating Temperature -10°C to +75°C
 Mating Connector AXE530124
